ACT4060A datasheet, converter equivalent, Qorvo

ACT4060A Features and benefits

* 2 A Output Current
* Up to 96% Efficiency
* 4.5 V to 24 V Input Range
* 10 µA Shutdown Supply Current
* 400 kHz Switching Frequency
* Adjustable.

ACT4060A Application

* TFT LCD Monitors
* Portable DVDs
* Car-Powered or Battery-Powered Equipment
* Set-Top Boxes
* Tele.

ACT4060A Description

The ACT4060A is a current-mode step-down DC/DC converter that provides up to 2 A of output current at 400kHz switching frequency. The device utilizes ActiveSemi’s proprietary high voltage process for operation with input voltages up to 24 V. The ACT4.

Image gallery
