HRW-124LM - Power Relay

This page provides the datasheet information for the HRW-124LM, a member of the HRW-SS-112L1 Power Relay family.

📥 Download Datasheet

Datasheet preview – HRW-124LM

Datasheet Details

Part number HRW-124LM
Manufacturer RC Electronics
File Size 217.09 KB
Description Power Relay
Datasheet download datasheet HRW-124LM Datasheet
Additional preview pages of the HRW-124LM datasheet.

📁 Similar Datasheet

  • HRW0202 - Silicon Schottky Barrier Diode for Rectifying (Hitachi Semiconductor)
  • HRW0202A - Silicon Schottky Barrier Diode for Rectifying (Hitachi Semiconductor)
  • HRW0202A - Silicon Schottky Barrier Diode (Renesas)
  • HRW0202A - Silicon Schottky Barrier Diode (Kexin)
  • HRW0202B - Silicon Schottky Barrier Diode for Rectifying (Hitachi Semiconductor)
  • HRW0202B - Silicon Schottky Barrier Diode (Renesas)
  • HRW0202B - Silicon Schottky Barrier Diode (Kexin)
  • HRW0203A - Silicon Schottky Barrier Diode for Rectifying (Hitachi Semiconductor)
  • HRW0203A - Silicon Schottky Barrier Diode (Kexin)
  • HRW0203A - Silicon Schottky Barrier Diode (Renesas)
Other Datasheets by RC Electronics

Full PDF Text Transcription

Click to expand full text
RC Mid-Range Power Relay--HRW-1 Shenzhen RC Electronics Co., Ltd. HRW-1 Feature 1. Low profile size: 20(L)x16(W)x20(H)mm 2. Switching Capacity: 15A/125VAC 10A 28VDC/250VAC 3. Low cost type Typical applications ◆Automotive ◆HVAC ◆Home Appliances ◆Power system ◆Industrial control ◆UPS Reference cross:JQC-21F 812H SRUDH SRU HM810 RC Specifications Mid-Range Power Relay--HRW-1 Shenzhen RC Electronics Co., Ltd. ◆ Contact Ratings Number of poles 1 Pole Arrangement 1 Form A, 1 Form B ,1 Form C Initial contact 50mΩ resistance, max.(by voltage drop 6VDC/1A) Contact material Silver alloy Rating Nominal switching 10A 250VAC (resistive load) capacity 15A 125VAC Max. switching power 2500VA Max. switching voltage 250VAC Max.
