B2412D-W5 Datasheet, Converter, REICU

B2412D-W5 Features

• Converter RoHS compliant Efficiency up to 80% 1.6kVDC Isolation Single output Short circuit protection( Suffix“R2”,optional) Industry standard requir3ed Wide temperature performance at full 0.5 W

PDF File Details

Part number:

B2412D-W5

Manufacturer:

REICU

File Size:

3.70MB

Download:

📄 Datasheet

Description:

Dc/dc converter.

TAGS

B2412D-W5

REICU
