SF18G Features
* Available in glass passivated chip junction with G suffix
* Low forward voltage drop
* High current capability
* Low leakage current
* Super fast switching speed < 35ns MECHANICAL DATA
* Molded plastic body (UL 94V-0 rated)
* Lead: Axial lea
Datasheet Details
SF18G, SF11
RFE
208.64 KB
Super fast recovery rectifier.
This datasheet PDF includes multiple part numbers: SF18G, SF11.
Please refer to the document for exact specifications by model.
