SF1063A 549.00 MHz SAW Filter

1 BOM,DEMOBOARD,SF1063A CAP,CHIP,NPO,12(J),STD CAP,CHIP,NPO,1.5(C),STD CAP,CHIP,NPO,1.0(C),STD FILTER,SM,549.000MHZ CONN,COAX,FLANGE MT.JACK IND,CHIP,0603,12NH,10% PCB, SMT FILTER, DESCRIPTION 2 QTY/ASSY REFERENCE DESCRIPTION 2.0000 1.0000 1.0000 1.0000 2.0000 2.0000 1.0000 C1 C2 C3 FLTR1 J1,2 L1,.

SF1063A Designed for CATV Applications (Pilot Tone) Low Insertion Loss 9.1 x 7.1 mm Surface-Mount Case Unbalanced Input and Output Complies with Directive 2002/95/EC (RoHS) Pb 549.00 MHz SAW Filter Value +10 30 -40 to +85 260°C for 30 s Units dBm VDC °C Absolute Maximum Ratings Rating Maximum Incident Power in Passband Max. DC voltage between any 2 terminals Storage Temperature Range Suitable for lead-free soldering - Max Soldering Profile SM.
