RF7176 Datasheet, Module, RFMD

RF7176 Features

  • Module
  • Enhanced Performance Transmit Module
  • High Efficiency at Rated POUT VBATT=3.5 GSM850/EGSM900=42% DCS1800/PCS1900=36%
  • Integrated Power Flattening Circuit

PDF File Details

Part number:

RF7176

Manufacturer:

RFMD

File Size:

693.26kb

Download:

📄 Datasheet

Description:

Quad-band tx / dual-band rx gsm/gprs transmit module. The RF7176 is a quad-band (GSM850/EGSM900/DCS1800/PCS1900) GSM/GPRS Class 12-compliant transmit module with two symmetrical receive p

Datasheet Preview: RF7176 📥 Download PDF (693.26kb)
Page 2 of RF7176 Page 3 of RF7176

RF7176 Application

  • Applications
  • GSM850/EGSM900/DCS1800/PCS1900 Products
  • 3V Multimode Mobile Applications
  • GPRS Class 12 Compliant

TAGS

RF7176
QUAD-BAND
DUAL-BAND
GSM
GPRS
TRANSMIT
MODULE
RFMD
