RP130K331D-TR Datasheet, Regulator, RICOH

RP130K331D-TR Features

• Regulator
• Supply Current Typ. 38μA
• Supply Current (Standby Mode) Typ. 0.1 μA
• Ripple Rejection Typ. 80dB (f=1kHz)
• Input Voltage Range 1.7V to 6.5V
<

PDF File Details

Part number:

RP130K331D-TR

Manufacturer:

RICOH

File Size:

518.81kb

Download:

📄 Datasheet

Description:

Low noise 150ma ldo regulator.

DFN(PLP)1010-4 Pin No 1 2 3 4 Symbol VOUT GND CE / CE VDD Pin Description Output Pin Ground Pin Chip Enable Pin ("L" Ac

RP130K331D-TR Application

• Applications
• Power source for battery-powered equipment.
• Power source for portable communication equipment.
• Power sour
