DB101 SILICON BRIDGE RECTIFIER

Rectron

Description

SINGLE-PHASE GLASS PASSIVATED SILICON BRIDGE RECTIFIER VOLTAGE RANGE 50 to 1000 Volts CURRENT 1.0 Ampere .
only.

📥 Download Datasheet

DB101 Datasheet Preview — Preview of DB101 PDF

Datasheet Specifications

Part number: DB101
Manufacturer: Rectron
File Size: 78.76 KB
Datasheet: DB101-Rectron.pdf
Description: SILICON BRIDGE RECTIFIER

Features

* Good for automation insertion
* Surge overload rating - 30 amperes peak
* Ideal for printed circuit board
* Reliable low cost construction utilizing molded
* Glass passivated device
* Polarity symbols molded on body
* Mounting position: Any
* Weight: 1.0 gram MECHAN

Applications

* and actual performance may vary over time. Rectron Inc does not assume any liability arising out of the application or use of any product or circuit. Rectron products are not designed, intended or authorized for use in medical, life-saving implant or other applications intended for life-sustaining o
