ISL6844, ISL6840 - Improved Industry Standard Single-Ended Current Mode PWM Controller

Renesas

Datasheet Details

Part number	ISL6844, ISL6840
Manufacturer	Renesas ↗
File Size	333.26 KB
Description	Improved Industry Standard Single-Ended Current Mode PWM Controller
Datasheet	ISL6840-Renesas.pdf
Note	This datasheet PDF includes multiple part numbers: ISL6844, ISL6840. Please refer to the document for exact specifications by model.

include low operating current, 60µA start-up current, adjustable operating frequency to 2MHz, and high peak current drive capability with 20ns rise and fall times. Part Number ISL6840 ISL6841 ISL6842 ISL6843 ISL6844 Rising UVLO (V) 7.0 7.0 14.4 8.4 14.4 MAX. Duty Cycle (%) 100 50 100 100 50 Related Literature For a full list of related documents, visit our website: ISL6840, ISL6841, ISL6842, ISL6843, ISL6844 device pages Features.
1A MOSFET gate driver.
60µA start-up curre.
