K1521, K1522 - 2SK1521

Renesas

📥 Download Datasheet

K1521 Datasheet Preview — This datasheet PDF includes multiple part numbers: K1521, K1522. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	K1521, K1522
Manufacturer	Renesas ↗
File Size	98.65 KB
Description	2SK1521
Datasheet	K1522_Renesas.pdf
Note	This datasheet PDF includes multiple part numbers: K1521, K1522. Please refer to the document for exact specifications by model.

K1521 Product details

Features

Low on-resistance High speed switching Low drive current Built-in fast recovery diode (trr = 120 ns) Suitable for motor control, switching regulator, DC-DC converter Outline TO-3PL D G 1 2 3 S 1. Gate 2. Drain 3. Source 2SK1521, 2SK1522 Absolute Maximum Ratings (Ta = 25°C) Item Drain to source voltage 2SK1521 2SK1522 Gate to source voltage Drain current Drain peak current Body to drain diode reverse drain current Channel dissipation Chan.
