SJ-S-112DMH, Miniature Power Relay

SANYOURELAYS Relays for advanced technology Contact Capacity Model Nominal switching capacity (res.load) Max.switching current Max.switching voltag.

datasheet Preview Page 1 from Datasheet4u.com

SJ-S-112DMH-SANYOU.pdf

SJ-S-112DMH Datasheet Preview — Preview of SJ-S-112DMH PDF

Datasheet Details

Part number:

SJ-S-112DMH

Manufacturer:

SANYOU

File Size:

86.50 KB

Description:

Miniature Power Relay

Features

* Advanced DEC DQ 1U technology and production line was introduced into from Japan
* Small size(18.2
* 10.2
* 15.5mm)with 12A switching capability for high density PCB mounting
* Surge voltage：10000V (between coil and contact)
* Patent number：ZL 2008201888176， ZL 2008201888180

Applications

* Home appliances, officee quipment, audioe quipment, car, air conditioner, etc. Characteristic Curves Max. SwitchingPower 50 20 10 8 5 ACRES 4 3 DCRES 2 10 20 30 100 200 300 400 Contact Voltage(V) 100 50 12A 8A 10 10A 5 0 5 10 15 conta at current(A) CoilTemp . Rise Percentage of N
