SDC177MJJ - Hall Switch IC
Package: TO-92S 3 2 1 OUT GND VCC Data Sheet SDC177MJJ Figure 2.
Pin layout serial number name Function 1 VCC Working input power 2 GND land 3 OUT Output pin SDC CONFIDENTIAL DOCUMENT Table1.PinDescription Functional Block Diagram VCC REG OUT Figure 3.
Functional block diagram
SDC177MJJ Features
* ÿWide operating voltage range: 3.5V~20V ÿBuilt -in temperature compensation circuit ÿOpen collector output ÿMaximum output current 25mA ÿPackage : TO-92S application ÿMahjong machine ÿElectronic switch ÿSpeed measurement Data Sheet SDC177MJJ SDC CONFIDENTIAL DOCUMENT TO-92S Figure 1. Package type
