SDC266 - Switch Hall IC

SDC266 Description

Switch Hall IC Datasheet SDC266 General .
The SDC266 is an integrated circuit which includes Hall sensor and output drive circuits.

SDC266 Features

* Wide operating voltage range: 3.5V~24V
* 250mA(AVG) output sink current
* Building-in protection diode
* Operating temperature range: -20°C~85°C

SDC266 Applications

* Brushless DC motor
* Brushless DC fan
* Revolution counting
* Speed measurement TO-94 Figure 1. Package Type August, 2014 Rev. 1.3 ©2014 Shaoxing Devechip Microelectronics Co. , Ltd. 1/8 www. sdc-semi. com Switch Hall IC Pin Configuration
