Part number: SA300C
Manufacturer: SEMITECH
File Size: 135.97KB
Download: 📄 Datasheet
Description: GLASS PASSIVATED JUNCTION TRANSIENT VOLTAGE SUPPRESSOR
z Glass Passivated Die Construction z 500W Peak Pulse Power Dissipation z Uni-directional Versions Available z Excellent Clamping Capability z Fast Response Time < 1 ns
.
z Communication Systems z Power Supplies z Medical Equipment z Business Machines
REF.
A b c D
DIMENSIONS
Millimeters
.
Image gallery
