1N60PW
FEATURES
- High Voltage
- Low Forward Voltage
APPLICATIONS
- For electronic calculator, etc.
Absolute Maximum Ratings (T a = 25o C)
Peak Reverse Voltage Reverse Voltage dc Peak Forward Current Average Rectified Output Current Surge Forward Current Junction Temperature Storage Temperature Range
Symbol
Value
Unit
I FM
150 m A
50 m A
Isurge
500 m A
Tj
-55 to +175
Characteristics
Symbol Test condition(Ta25±2o C) Min. Typ. Max. Unit
Forward Current
IF VF = 1V
- - m A
Reverse Current 1N 60PW
Reverse Voltage
1N 60SW
Junction Capacitance
Rectification efficiency
IR VR = 10V
IR VR = 10V
VR IR = 100 u A
- f = 1MHz, V = -1V n
Vi = 2Vrms, R = 5KΩ C = 20PF, f = 40MHz
-...
