KBPC2506W, KBPC25005W - HIGH CURRENT SINGLE-PHASE SILICON BRIDGE RECTIFIERS

Name: KBPC2506W
SKU: KBPC2506W-1215106

SEMTECH

The KBPC2506W by SEMTECH is a HIGH CURRENT SINGLE-PHASE SILICON BRIDGE RECTIFIERS. Below is the official datasheet preview.

Datasheet Details

Part number	KBPC2506W, KBPC25005W
Manufacturer	SEMTECH
File Size	399.16 KB
Description	HIGH CURRENT SINGLE-PHASE SILICON BRIDGE RECTIFIERS
Datasheet	KBPC25005W-SEMTECH.pdf
Note	This datasheet PDF includes multiple part numbers: KBPC2506W, KBPC25005W. Please refer to the document for exact specifications by model.
Additional preview pages of the KBPC2506W datasheet.

Surge overload 300 Amperes peak.
Low power loss, high efficiency.
Low reverse leakage current HAbsolute Maximum Ratings and Characteristics Rating at 25oC ambient temperature unless otherwise specified. resistive or inductive load 60 Hz,. CFor capacitive load current by 20%. Characteristic KBPC KBPC KBPC KBPC KBPC KBPC 25005W 2501W 2502W 2504W 2506W 2508W KBPC 2510W Units EMaximum Recurrent Peak Reverse Voltage 50 100 200 400 600 800 1000 V Maximum RMS Voltag.
