ZMC1
Features
- Fits onto SOD-323 / SOT-23 footprints
- Micro MELF package
LS-31
1.2±0.05 Gl1.a3s5s Max.
Cathode indification
0.19±0.05 2±0.1
2.5 Glass R
Glass case Micro MELF
HDimensions in mm
Absolute Maximum Ratings (Ta = 25 OC)
CParameter
Power Dissipation
EJunction Temperature
Storage Temperature Range
T1) Valid provided that electrodes are kept at ambient temperature
Symbol Ptot Tj Tstg
Value 500 1) 175
- 55 to + 175
Unit m W OC OC
MCharacteristics at Ta = 25 OC EParameter
SThermal Resistance Junction to Ambient Air
Symbol Rth A
Max. 0.3 1)
Unit K/m W
Forward Voltage at IF = 100 m A
VF 1
1) Valid provided that electrodes are kept at ambient temperature
SEMTECH ELECTRONICS LTD.
Subsidiary of Sino-Tech International (BVI) Limited
®
Dated : 10/09/2009
ZMC1…ZMC75
Characteristics at Ta = 25 OC
Zener Voltage 1)
Type
VZnom
VZT at IZT
Dynamic Resistance ZZT ZZK at...
