Datasheet Details
Part number:
ZPD11B, ZPD2V7B
Manufacturer:
SEMTECH
File Size:
461.32 KB
Description:
Silicon epitaxial planar zener diodes.
Note:
This datasheet PDF includes multiple part numbers: ZPD11B, ZPD2V7B.
Please refer to the document for exact specifications by model.
ZPD2V7BZPD75B Silicon Epitaxial Planar Zener Diodes Max.
0.5 Max.
1.9 Min.
27.5 Black Cathode Band Black Part No.
Black "ST" Brand XXX ST Max.
3.9 Min.
27.5 SEMTECHGlass Case DO-35 Dimensions in mm Absolute Maximum Ratings (Ta = 25 OC) Parameter Symbol Value Unit Power Dissipation Ptot 500 1) mW Junction Temperature Tj 175 OC Storage Temperature Range Tstg - 55 to + 175 OC 1) Valid provided that leads are kept at ambient temperature at a distance of 8 mm from case.
Char
