SGM4027 - CMOS Voltage Reference

Description

The SGM4027 is a precision, low power, low noise and low dropout voltage reference, which is designed to offer low temperature drift and high initial accuracy while consuming only 245μA (TYP) quiescent current.

Features

  • high precision and low power consumption. The combination of these characteristics makes the device ideal for use in industrial.

📥 Download Datasheet

Datasheet Details

Part number SGM4027
Manufacturer SG Micro
File Size 1.52 MB
Description CMOS Voltage Reference
Datasheet download datasheet SGM4027 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
SGM4157 DPDT Analog Switch Shengbang Microelectronics
SGM44599 DPDT Analog Switch Shengbang Microelectronics
SGM44600 DPDT Analog Switch Shengbang Microelectronics
SGM44601 DPDT Analog Switch Shengbang Microelectronics
SGM44602 DPDT Analog Switch Shengbang Microelectronics

Other Datasheets by SG Micro

Part Number Description
SGM4027A CMOS Voltage Reference
SGM4025 CMOS Voltage Reference
SGM4029 Precision Voltage Reference
SGM4040 Micro-Power Precision Shunt Voltage Reference
SGM4041 Micro-Power Precision Shunt Voltage Reference

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
SGM4027 35ppm/℃, 245μA, CMOS Voltage Reference GENERAL DESCRIPTION The SGM4027 is a precision, low power, low noise and low dropout voltage reference, which is designed to offer low temperature drift and high initial accuracy while consuming only 245μA (TYP) quiescent current. The SGM4027 features high precision and low power consumption. The combination of these characteristics makes the device ideal for use in industrial applications, such as transmitters of temperature and pressure. To keep the stability and decrease the output noise of the output voltage, a capacitor with the capacitance of 2μF to 22μF should be added at the output pin of SGM4027. For the typical operation, the power supply voltage should be 0.2V beyond the VREF.
