MDS INTEGRATED CIRCUIT
RHYTHM GENERATOR
~ INTERNAL TEMPO OSCILLATOR , 6 PROGRAMMABLE RHYTHMS i DRIVES 5 SOUND GENERATORS
- MASK PROGRAMMABLE RESET COUNTS: 12 or 16
- DOWN BEAT OUTPUT
- EXTERNAL RESET
- LOW POWER DISSIPATION: < 100 mW
- PIN-TO-PIN PATIBLE WITH MM 5871
- PUSH-PULL OR OPEN DRAIN OUTPUTS AVAI LABLE II STANDARD CONTENT AVAILABLE ,"he M 255 is a monolithic rhythm generator specifically designed for electronic organs and other musical Instruments. Constructed on a single chip using P-channel silicon gate technology it is supplied in a 16-lead dual in-line plastic package. f_
"BSOLUTE MAXIMUM RATINGS-
"".GG
- -
V,"" fo
Ir"s,tg roil
Source supply voltage Input voltage Output...
