SPT7760 - 8-BIT / 1 GSPS FLASH A/D CONVERTER

📥 Download Datasheet

SPT7760 Datasheet Preview — Preview of SPT7760 PDF

Datasheet Details

Part number: SPT7760
Manufacturer: SPT
File Size: 98.79 KB
Datasheet: SPT7760_SPT.pdf
Description: 8-BIT / 1 GSPS FLASH A/D CONVERTER

SPT7760 Product details

Description

The SPT7760 is a full parallel (flash) analog-to-digital converter capable of digitizing full scale (0 to -2 V) inputs into eight-bit digital words at an update rate of 1 GSPS.

Features

1:2 Demuxed ECL Compatible Outputs Wide Input Bandwidth - 900 MHz Low Input Capacitance - 15 pF (MQUAD) Metastable Errors Reduced to 1 LSB Monolithic for Low Cost Gray Code Output.
