ST7538 - POWER LINE FSK TRANSCEIVER

Datasheet Summary

Description

The ST7538 is a Half Duplex synchronous/asynchronous FSK Modem designed for power line communication network applications.

It operates from a single supply voltage and integrates a line driver and a 5V linear regulator.

ST Microelectronics

📥 Download Datasheet

Datasheet Details

Part number	ST7538
Manufacturer	STMicroelectronics
File Size	264.96 KB
Description	POWER LINE FSK TRANSCEIVER
Datasheet	ST7538 Datasheet
