74ACT573 - OCTAL D-TYPE LATCH

74ACT573 Description

® 74ACT573 OCTAL D-TYPE LATCH WITH 3 STATE OUTPUT NON INVERTING s s s s s s s s s HIGH SPEED: tPD = 5 ns (TYP.) at VCC = 5V LOW POWER DISSIP.
The ACT573 is an advanced high-speed CMOS OCTAL D-TYPE LATCH with 3 STATE OUTPUT NON INVERTING fabricated with sub-micron silicon gate and double-laye.

74ACT573 Applications

* mantaining high speed operation similar to equivalent Bipolar Schottky TTL. These 8 bit D-Type latch are controlled by a latch enable input (LE) and an output enable input (OE). PIN CONNECTION AND IEC LOGIC SYMBOLS While the LE inputs is held at a high level, the Q outputs will follow the data inpu
