Part number: HCF40106
Manufacturer: STMicroelectronics (https://www.st.com/)
File Size: 328.65KB
Download: 📄 Datasheet
Description: Hex Schmitt trigger
* Schmitt trigger action with no external components
* Hysteresis voltage typically: 0.9 V at VDD = 5 V 2.3 V at VDD =10 V 3.5 V at VDD =15 V
* Noise immunity.
* Automotive
* Industrial
* Computer
* Consumer
Description
The HCF40106 is a monolithic integrated circ.
The HCF40106 is a monolithic integrated circuit fabricated in metal oxide semiconductor technology available in an SO-14 package.
The HCF40106 consists of six Schmitt trigger circuits. Each circuit functions as an inverter with Schmitt trigger action.
