STA540 - 4 x 13 W dual/quad power amplifier

Product Overview

STMicroelectronics

📥 Download Datasheet

STA540 4 x 13 W dual/quad power amplifier by STMicroelectronics - Datasheet Preview — Datasheet preview – STA540

Datasheet Details

Part number	STA540
Manufacturer	STMicroelectronics
File Size	284.73 KB
Description	4 x 13 W dual/quad power amplifier
Datasheet	STA540 Datasheet
Additional preview pages of the STA540 datasheet.

Product details

Features

High output power capability.
2x 38 W into 4 Ω at 18 V, 1 kHz, 10% THD.
2x 34 W into 8 Ω at 22 V, 1 kHz, 10% THD.
2x 24W into 4Ω at 14.4 V, 1 kHz, 10% THD.
2x 15 W into 8 Ω at 16 V, 1 kHz, 10% THD.
4x 13 W into 2 Ω at 15 V, 1 kHz, 10% THD.
4x 11 W into 4 Ω at 18 V, 1 kHz, 10% THD.
4x 7 W into 4 Ω at 14.4 V, 1 kHz, 10% THD.
Minimum external components count:.
no bootstrap capacitors.
no Boucherot cells.
