STM32U5G9NJ

160MHz ULP Cortex-M33 MCU

STMicroelectronics

STM32U5G9NJ Features

* Includes ST state-of-the-art patented technology Ultra-low-power with FlexPowerControl

* 1.71 V to 3.6 V power supply

* - 40 °C to + 85°C temperature range

* LPBAM: autonomous peripherals with DMA, functional down to Stop 2 mode

* VBAT mode: supply for RTC, 32 x 32-b

STM32U5G9NJ Datasheet (6.75 MB)

STM32U5G9NJ Datasheet Preview — Preview of STM32U5G9NJ PDF

Datasheet Details

Part number:

STM32U5G9NJ

Manufacturer:

STMicroelectronics ↗

File Size:

6.75 MB

Description:

160mhz ulp cortex-m33 mcu.
STM32U5Gxxx 2.5D and vector graphics, JPEG codec, LTDC, MIPI®DSI, 160 MHz ULP Cortex®-M33 MCU, 4 MB flash, 3 MB SRAM, crypto Datasheet - production d.
