TSV911A - 8-MHz operational amplifiers

STMicroelectronics

📥 Download Datasheet

TSV911A Datasheet Preview — Preview of TSV911A PDF

Datasheet Details

Part number: TSV911A
Manufacturer: STMicroelectronics ↗
File Size: 960.65 KB
Datasheet: TSV911A-STMicroelectronics.pdf
Description: 8-MHz operational amplifiers

TSV911A Product details

Description

The TSV91x and TSV91xA operational amplifiers (op amps) offer low voltage operation and rail-to-rail input and output, as well as an excellent speed/power consumption ratio, providing an 8 MHz gain-bandwidth product while consuming only 1.1 mA maximum at 5 V.

Features

Rail-to-rail input and output.
Wide bandwidth.
Low power consumption: 820 µA typ.
Unity gain stability.
High output current: 35 mA.
Operating from 2.5 V to 5.5 V.
Low input bias current, 1 pA typ.
Low input offset voltage: 1.5 mV max. (A grade).
ESD internal protection ≥ 5 kV.
Latch-up immunity.
