S2D 2.0A SURFACE MOUNT GLASS PASSIVATED RECTIFIER

S2D Description

S2A-S2M Technical Data Data Sheet N0562, Rev.A S2A THRU S2M 2.0A SURFACE MOUNT GLASS PASSIVATED RECTIFIER .

S2D Features

* SMB
* Glass Passivated Die Construction
* Ideally Suited for Automatic Assembly
* Low Forward Voltage Drop
* Low Power Loss
* Built-in Strain Relief
* Plastic Case Material has UL Flammability Classification Rating 94V-0
* This is a Pb
* Free Device
* All SM

📥 Download Datasheet

Preview of S2D PDF
datasheet Preview Page 2 datasheet Preview Page 3
