A1568 - 2SA1568
Built-in Diode at C E Low VCE (sat) 2SA1568 sElectrical Characteristics Symbol ICBO IEBO V(BR)CEO hFE VCE(sat) VFEC fT COB Conditions VCB= 60V VEB= 6V IC= 25mA VCE= 1V, IC= 6A IC= 6A, IB= 0.3A IECO= 10A VCE= 12V, IE=0.5A VCB= 10V, f=1MHz (Ta=25°C) 2SA1568 100max 60max 60min 50min 0.35max 2.5max 40typ 330typ V V MHz pF 13.0min ( 250 Ω ) E B Equivalent curcuit
