SAI02 Datasheet, Type, Sanken electric

SAI02 Features

• Type q Surface-mount package with high output and efficiency q Requires only 4 external components q Phase correction and output voltage adjustment performed internally q Built-in reference

PDF File Details

Part number:

SAI02

Manufacturer:

Sanken ↗ electric

File Size:

49.01kb

Download:

📄 Datasheet

Description:

Surface-mount/ separate excitation switching type.

SAI02 Application

• Applications q For power supplies in telephone sets q For power supplies in office equipment External View s Lineup Type No. SAI01 SAI02 SAI03 SAI0
