DP12F554S, DP12F351S Datasheet - Sanyo Denki

DP12F554S, DP12F351S, The 5-phase stepping Set

Pulse I/F (DC power input) The 5-phase Stepping Set DP1 series DC24V/36V Micro-step (500 x 1 to 250 divisions) Configuration of the 5-phase Stepping.

datasheet Preview Page 1 from Datasheet4u.com

DP12F351S-SanyoDenki.pdf

DP12F554S Datasheet Preview — This datasheet PDF includes multiple part numbers: DP12F554S, DP12F351S. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

DP12F554S, DP12F351S

Manufacturer:

Sanyo Denki

File Size:

269.78 KB

Description:

The 5-phase stepping Set

Note:

This datasheet PDF includes multiple part numbers: DP12F554S, DP12F351S.
Please refer to the document for exact specifications by model.

Applications

* Compact Mounting dedicated HIC realizes highly integrated and higher reliable system. Built-in function Resolution setting function 16 types of resolution, ranging from one to 250 divisions, can be set for a standard stepping motor step angle by using rotary switches. Step angle selectable Two typ
