* for your particular model, the program codes must be correct. Note 1. Option Data 1 (NO. 087 OP1) should be hexadecimal 00. See 087 above. If this program code is wrong the TV will not operate properly. Note 2. Option Data 2 (NO. 088 OP2) should be hexadecimal 03. See 088 above. If this program code
DP26640
Sanyo
3.21 MB
Remote control digital color television service manual.
FILE NO.
SERVICE MANUAL
Remote Control Digital Color Television
DP26640
(U.S.A.) (CANADA)
ORIGINAL VERSION
Chassis No. P26640-06
NOTE: Match th.
