SKKT19 Datasheet - Semikron

SKKT19 Thyristor

VRSM VRRM (dv/dt)cr VDRM V 700 900 1300 1500 1700 V 600 800 1200 1400 1600 V/µs 500 500 1000 1000 1000 ITRMS (maximum value for continuous operation) 40 A ITAV (sin. 180; Tcase = 60 °C) 25 A SKKT 19/06 D SKKT 20/06 D SKKT 19/08 D SKKT 20/08 D SKKT 20B08 D SKKT 19/12 E SKKT 20/12 E SKKT 20B12 E SKKT 19/14 E SKKT 20/14 E SKKT 20B14 E SKKT 19/16 E SKKT 20/16 E SKKT 20B16 E SEMIPACK® 1 Thyristor Modules SKKT 19 SKKT 20 SKKT 20B Symbol Conditions ITAV ID IRMS ITSM i2.

SKKT19 Features

* Heat transfer through aluminium oxide ceramic isolated metal baseplate

* Hard soldered joints for high reliability

* UL recognized, file no. E 63 532 Typical Applications

* DC motor control (e.g. for machine tools)

* AC motor soft starters

* Temperat

SKKT19 Datasheet (272.50 KB)

SKKT19 Datasheet Preview — Preview of SKKT19 PDF

Datasheet Details

Part number:

SKKT19

Manufacturer:

Semikron

File Size:

272.50 KB

Description:

Thyristor.
