SC2063 Datasheet - Semiment

Ultra-Low-Power Ominipolar Switch Hall Effect Sensor

SC2063 Features

* Industry ultra-low power consumption - 1.2 µA with 3.0 V

* 1.65V to 5.5V operating range

* Push-Pull and Open-Drain output options

* SOT-23 and TO-92 package options

* 40°C to +85°C operating temperature range APPLICATIONS

* Battery-critical position sensing

SC2063 General Description

The SC206X family is an ultra-low-power Omnipolar switch Hall effect sensor, designed for the most compact and battery-sensitive systems. The device is offered in multiple magnetic thresholds, sampling rates, output drivers, and packages to accommodate various applications. When the applied magnetic.

SC2063 Datasheet (1.09 MB)

SC2063 Datasheet Preview — Preview of SC2063 PDF

Datasheet Details

Part number:

SC2063

Manufacturer:

Semiment

File Size:

1.09 MB

Description:

Ultra-low-power ominipolar switch hall effect sensor.
