SC2442 Datasheet, Controller, Semtech Corporation

SC2442 Features

• Controller include: bootstrapping for high side drive supplies, asynchronous mode start up, power up sequencing to prevent latchups, individual soft start for each convertor, bootstrapped drivers

PDF File Details

Part number:

SC2442

Manufacturer:

Semtech Corporation

File Size:

357.83kb

Download:

📄 Datasheet

Description:

High performance wide input range dual synchronous buck controller. SC2442 and SC2442H are high performance dual buck converter controllers that can be configured for a variety of synchronous buck appl

SC2442 Application

• Applications where efficiency is most important. Both converters are synchronized to prevent beat frequencies. The dual buck converters are also ope
