PC81710NIP1B

Photocoupler

PC81710NIP1B Features

* 1. 4-pin DIP package 2. Double transfer mold package (Ideal for Flow Soldering) 3. Low input current type(IF=0.5mA) 4. High noise immunity due to high common mode rejection voltage (CMR : MIN.10kV/μs) 5. High collector-emitter voltage(VCEO : 80V) 6. High isolation voltage between input and output (V

PC81710NIP1B General Description

PC8171xNSZ1B Series contains an IRED optically coupled to a phototransistor. It is packaged in a 4-pin DIP. Input-output isolation voltage(rms) is 5kV. Collector-emitter voltage is 80V. CTR is 100% to 600% (at IF=0.5mA,VCE=5V,Ta=25℃)
* Agency approvals/Compliance 1. Recognized by UL1577 (Double.

PC81710NIP1B Datasheet (1.39 MB)

Preview of PC81710NIP1B PDF

Datasheet Details

Part number:

PC81710NIP1B

Manufacturer:

Sharp

File Size:

1.39 MB

Description:

Photocoupler.
