SGM9123 Datasheet, Drivers, Shengbang Microelectronics

SGM9123 Features

• Drivers Triple 3rd order 8MHz (SD) Filters Transparent Input Clamping 6dB Output Driver Gain and Drive Dual Video Load Rail-to-Rail Output Input Voltage Range Includes Ground AC or DC Coupled I

PDF File Details

Part number:

SGM9123

Manufacturer:

Shengbang Microelectronics

File Size:

582.19kb

Download:

📄 Datasheet

Description:

3rd order sdtv video filter drivers. SGM9123 is a video buffer which integrates triple 6dB Gain rail-to-rail output driver and triple 3rd output reconstruction filter, it

SGM9123 Application

• Applications SGM9123 can be DC-coupled or AC-coupled with input video signal, such as the output stage of DAC to eliminate out-of-band noise. Inter
