D5SBA20
FEATURES
- œ Thin Single In-Line Package
- œ High IFSM
- œ Applicable to Automatic Insertion APPLICATION
OUTLINE DIMENSIONS
Case : 5S
Unit : mm
- œ Switching power supply
- œ Home Appliances, Office Equipment
- œ Telemunication, Factory Automation
RATINGS
- œAbsolute Maximum Ratings (If not specified Tc=25- Ž) Item Symbol Conditions Ratings Unit Storage Temperature Tstg -40- `150
- Ž Operating Junction Temperature Tj 150
- Ž Maximum Reverse Voltage VRM 200 V IO 50Hz sine wave, R-load With heatsink Tc=111- Ž Average Rectified Forward Current 6 A 50Hz sine wave, R-load Without heatsink Ta=25- Ž 2.8 Peak Surge Forward Current IFSM 50Hz sine wave, Non-repetitive 1cycle peak value, Tj=25- Ž 120 A Current Squared Time I2t 1ms- …t- ƒ10ms- @Tj=25- Ž 60 A2 s Dielectric Strength Vdis Terminals to case, AC 1 minute 2 k V Mounting Torque R i emended torque- F 0.5N- m- j TOR
- 0.8 N- m
- œElectrical Characteristics (If not specified Tc=25- Ž) Item Symbol Conditions Ratings Unit V Forward Voltage =3.0A, Pulse...
