DE10PC3

Schottky Rectifiers (SBD) (30V 10A)

DE10PC3 Features

* œ SMT

* œ Super low VF=0.4V

* œ High current capacity with Small Package APPLICATION

* œ Reversed OUTLINE DIMENSIONS Case : E-pack Unit : mm Battery Connection Protection

* œ DC OR output

* œ DC/DC converter

* œ Mobile telephone, personal computer

DE10PC3 Datasheet (533.61 KB)

Preview of DE10PC3 PDF

Datasheet Details

Part number:

DE10PC3

Manufacturer:

Shindengen Electric Mfg.Co.Ltd

File Size:

533.61 KB

Description:

Schottky rectifiers (sbd) (30v 10a).
