DF20LC20U

Super Fast Recovery Rectifiers

DF20LC20U Features

* œ SMT OUTLINE DIMENSIONS Case : STO-220 Unit : mm

* œ Low noise

* œ trr35ns APPLICATION

* œ Switching power supply

* œ DC/DC converter

* œ Free Wheel

* œ Home Appliances, Office Equipment

* œ Telecommunication, Factory Automation RATINGS

DF20LC20U Datasheet (375.78 KB)

Preview of DF20LC20U PDF

Datasheet Details

Part number:

DF20LC20U

Manufacturer:

Shindengen Electric Mfg.Co.Ltd

File Size:

375.78 KB

Description:

Super fast recovery rectifiers.
