AN-SY6280

Low Loss Power Distribution Switch

AN-SY6280 Features

* Distribution voltages: 2.4V to 5.5V

* Programmable current limit

* Enable polarity: active high

* Over temperature shutdown and automatic retry

* Reverse blocking (no body diode)

* At shutdown, OUT can be forced higher than IN

* Automatic out

AN-SY6280 General Description

The SY6280 develops ultra-low Rds(on) switch with programmable current limiting to protect the power source from over current and short circuit conditions. It integrates the over temperature protection and discharges the output capacitor during the shutdown. In case the output is pulled higher than .

AN-SY6280 Datasheet (291.67 KB)

Preview of AN-SY6280 PDF

Datasheet Details

Part number:

AN-SY6280

Manufacturer:

Silergy

File Size:

291.67 KB

Description:

Low loss power distribution switch.
