SI4112G

DUAL-BAND RF SYNTHESIZER

SI4112G Features

* " " RF1: 900 MHz to 1.8 GHz RF2: 750 MHz to 1.5 GHz IF: 500 MHz to 1000 MHz ! ! ! ! ! ! IF Synthesizer " Integrated VCOs, Loop Filters, ! ! Varactors, and Resonators Minimal External Components Required Applications Pin Assignments ! GSM, DCS1800, and PCS1900 Cellular Telephones ! ! GPRS Da

SI4112G General Description

The Si4133G is a monolithic integrated circuit that performs both IF and dual-band RF synthesis for GSM and GPRS wireless communications applications. The Si4133G includes three VCOs, loop filters, reference and VCO dividers, and phase detectors. Divider and power down settings are programmable thro.

SI4112G Datasheet (559.31 KB)

Preview of SI4112G PDF

Datasheet Details

Part number:

SI4112G

Manufacturer:

Silicon Laboratories

File Size:

559.31 KB

Description:

Dual-band rf synthesizer.
Si41 33G Si412 3G/22G/13G/12G D U A L -B A N D R F S Y N T H E S I Z E R W I T H I N T E G R A T E D V C O S FOR GSM AND GPRS WIRELESS COMMUNICATIONS .
