HV6
FEATURES
- Fast recovery times
- High surge capability
- Low leakage current
- High current capability
- High voltage
0(&+$1,&$/'$7$
Case: DO-15 molded plastic body Terminals: Plated axial leads, solderable per MIL-STD-750, Method 2026 Polarity: Color band denotes cathode end Mounting Position: Any Weight:0.36 grams
3DUW0DUNLQJ6VWHP
Cathode Band
Rectifiers
Zener
Switching
DIAC
1SPEVDU5ZQF Logo
0$;,0805$7,1- 6$1'(/(&75,&$/&+$5$&7(5,67,&6
Ratings at 25 C ambient temperature unless otherwise specified. Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%.
PARAMETER
SYMBOL
Maximum repetitive peak reverse voltage Maximum RMS voltage Maximum DC blocking voltage
Maximum average forward rectified current 0.375”(9.5mm) lead length at TA=50 ℃
VRRM VRMS VDC
I(AV)
Peak forward surge current 8.3ms single half sine- wave superimposed on rated load (JEDEC Method)
IFSM
Maximum instantaneous forward voltage at...
