SD1010D - Digital Interface XGA TFT LCD Display Controller

SD1010D Datasheet Preview — Preview of SD1010D PDF

Datasheet Details

Part number	SD1010D
Manufacturer	SmartASIC
File Size	243.97 KB
Description	Digital Interface XGA TFT LCD Display Controller
Datasheet	SD1010D_SmartASIC.pdf

SD1010D Product details

Description

Figure 2: SD1010D package diagram 102 120 1031 21 65 81 64 80 SmartASIC SD1010D 1281 60 1 38 40 39 41 525 Race Street, Suite 250, San Jose, CA 95126, USA.Main: (408) 283-5098 Fax: (408) 283-5099 Table 1: SD1010 pin description (sorted by pin number) Symbol ROM_SCL ROM_SDA GND CPU_SCL CPU_SDA PWM_CTL CLK_1M VDD CLK_1M_O RESET_B R_OSD G_OSD B_OSD EN_OSD PIN Number 1 2 3 4 5 6 7 8 9 10 11 12 13 14 I/O Description O SCL in I2C for EEPROM interface I/O SDA in I2C for EEPROM interface Ground I

Features

to the TFT LCD monitor solution. The first one is “plug-and-play”, and the second one is “cost-effective system solution”. To be truly plug-and-display, the SD1010D performs automatic input mode detection. Furthermore, the SD1010D can generate output video even when the input signal is beyond the specifications or no input signal is fed. For “cost-effective system solution”, the SD1010D implements many system support features such as OSD mixer, error status indicators, 2-wire serial interface fo.
