S2916 - Tx-Rx FEM

Product Overview

Datasheet Details

Part number	S2916
Manufacturer	Smarter Micro
File Size	839.93 KB
Description	Tx-Rx FEM
Datasheet	S2916 Datasheet
Additional preview pages of the S2916 datasheet.

Product details

Description

Smarter Micro’s S2916 is Transmit and Receive Front End Module (FEM) with the capability to support Quad-Band GSM/GPRS/EDGE, TD-SCDMA B34/B39 and TDD-LTE B39 frequency bands.

Features

GSM, GPRS and EDGE Transmit.
TD-SCDMA Compliant.
TD-HSDPA and TD-HSPA+ Compliant.
TDD-LTE Band39 Compliant.
Fourteen High Linearity TRx switch ports.
High Efficiency at Rated Pout.
Input/output RF ports matched internally to 50Ω load.
Integrated directional coupler.
MIPI RFFE Digital Control.
Support Linear or VRAMP-based GMSK power control.
RF input switching to 3G/4G path.
Robust 8kV ESD protection at Antenna port.
Small, low pr.
