CXA1102P, CXA DOLBY B TYPE NOISE REDUCTION SYSTEM

Sony Corporation

CXA1102P Description

CXA1100P, CXA1101P/M, CXA1102P/M, CXA1163P/M Dolby∗ B Type Noise Reduction System For the availability of this product, please contact the sales offic.
CXA1100, CXA1101, CXA1102 and CXA1163 are ICs including two separate Dolby B type noise reduction processors.

CXA1102P Features

* Minimum number of external components
* NR ON/OFF and REC/PB switchs included
* Small package (DIP16, SOP16) ~ 5.5mA, Typ. )
* Small supply current (
* Dual channel processors in one chip Absolute Maximum Ratings (Ta = 25°C)
* Supply voltage

📥 Download Datasheet

CXA1102P Datasheet Preview — This datasheet PDF includes multiple part numbers: CXA1102P, CXA. Please refer to the document for exact specifications by model.

Datasheet Details

Part number: CXA1102P, CXA
Manufacturer: Sony Corporation
File Size: 473.58 KB
Datasheet: CXA-1100.pdf
Description: DOLBY B TYPE NOISE REDUCTION SYSTEM
Note: This datasheet PDF includes multiple part numbers: CXA1102P, CXA.
Please refer to the document for exact specifications by model.
