CXD1948R - IEEE1394 Link Layer LSI for DVB and DSS

Product Overview

Sony Corporation

📥 Download Datasheet

CXD1948R IEEE1394 Link Layer LSI for DVB and DSS by Sony Corporation - Datasheet Preview — Datasheet preview – CXD1948R

Datasheet Details

Part number	CXD1948R
Manufacturer	Sony Corporation
File Size	718.90 KB
Description	IEEE1394 Link Layer LSI for DVB and DSS
Datasheet	CXD1948R Datasheet
Additional preview pages of the CXD1948R datasheet.

Product details

Description

The CXD1948R is a Link Layer LSI conforming to the IEEE1394 serial bus standard.

Features

Conforms to IEEE1394 serial bus standard.
Supports DVB and DSS transport streams.
Dedicated ports for asynchronous data/isochronous data.
Isochronous data inserted from asynchronous data port.
Smoothing buffer function.
Large capacity FIFO Isochronous transmit/receive FIFO 960 × 32 bits Asynchronous transmit FIFO 30 × 33 bits Asynchronous receive FIFO 36 × 33 bits Isochronous Insert Packet Transmit Buffer 47 × 33 bits.
CIP header au.
