LI1206xxxxx-10, LI1206H151R-10 - Surface Mount Ferrite Chip

The LI1206xxxxx-10 by Steward is a Surface Mount Ferrite Chip. Below is the official datasheet preview.

LI1206xxxxx-10 Surface Mount Ferrite Chip by Steward - Datasheet Preview — Official preview page of the **LI1206xxxxx-10** Surface Mount Ferrite Chip datasheet (Steward).

Datasheet Details

Part number	LI1206xxxxx-10, LI1206H151R-10
Manufacturer	Steward
File Size	314.55 KB
Description	Surface Mount Ferrite Chip
Datasheet	LI1206H151R-10_Steward.pdf
Note	This datasheet PDF includes multiple part numbers: LI1206xxxxx-10, LI1206H151R-10. Please refer to the document for exact specifications by model.
Additional preview pages of the LI1206xxxxx-10 datasheet.

LI1206xxxxx-10 Product details

Description

HI High Current Chips ( > 3 Amps) MI Mid Current Chips (1-2.5 Amps) HR High Retention Under Bias LI Low Current Chips (< 1 Amp and < 400 Ohms) HZ High Impedance Chips ( 400 Ohms) HF High Frequency Chip Array Ambient Operating Temperature Range: -55°C to +125°C PART NUMBER METRIC (EIA) PKG.SIZE IMPEDANCE (Z) TYPICAL OHMS @ 100 MHz 500 MHz 1 GHz DCR MAX (Ohms) RATED I MAX (continuos) mA PART NUMBER METRIC (EIA) PKG.SIZE IMPEDANCE (Z) TYPICAL OHMS @ 100 MHz 500 MHz 1 GHz Chip Bead

Features

Small footprint.
Excellent retention under bias.
Rugged, monolithic construction.
Superior impedance vs. frequency characteristics.
Economical.
Broad range of sizes ( from 0402 up to 3312 ).
Broad range of impedance values and current ratings www. datasheet4u. com.
