1SMB90 Features
* ! Glass Passivated Die Construction ! Uni- and Bi-Directional Versions Available ! Excellent Clamping Capability ! Fast Response Time ! Plastic Material: UL Flammability Classification Rating 94V-0 Mechanical Data ! Case: SMB, Transfer Molded Epoxy ! Terminals: Solderable per MIL-STD-202, Method 208
Datasheet Details
1SMB90, 1SMB5.0
Sunmate
861.71 KB
Surface mount transient volage suppessor diode.
This datasheet PDF includes multiple part numbers: 1SMB90, 1SMB5.0.
Please refer to the document for exact specifications by model.
