BAS16D
Features
! High Conductance
! Fast Switching Speed ! Surface Mount Package Ideally Suited for
Automatic Insertion ! For General Purpose Switching Application ! Plastic Material
- UL Recognition Flammability
Classification 94V-O
Mechanical Data
! C ase: S O D -1 23FL plastic body over passivated junction
! Terminals : Plated axial leads,
! solderable per MIL-STD-750, Method 2026
! Polarity : Color band denotes cathode end
! Mounting Position : Any
! Weight:0.0007 ounce, 0.02 grams
Maximum Ratings @ TA = 25°C unless otherwise specified
Characteristic
Non-Repetitive Peak Reverse Voltage
Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage
RMS Reverse Voltage
Forward Continuous Current (Note 1)
Average Rectified Output Current (Note 1)
Non-Repetitive Peak Forward Surge Current
@ t = 1.0µs @ t = 1.0s
Power Dissipation (Note 1)
Typical Thermal...
